Accustic Arts MONO IV Pair – Reference Class Mono Power Amplifiers

Description

Accustic Arts MONO IV Pair – Reference Class Mono Power Amplifiers

Accustic Arts bring to market true Reference Level Monoblock Amplifiers that redefine what is achievable in the segment.

A sonic that is both gloriously rich, deep and organic, mated to the perfect balance of dynamic drive and energy and just the most staggeringly holographic soundstage that has ever graced the design studios in Lauffen, Germany.

This is Accustic Arts new benchmark in Mono Power Amplifier performance circles……..

(Price is based on the supply of a pair of MONO IV Power Amplifiers)

MONO IV highlights

• Reference class mono power amplifier
• 20 selected MOS-FET output transistors of finest quality
• Two magnetically shielded and encapsulated toroidal core transformers of premium quality for highest output reserves
• Maximum total transformer power: 1200 VA (watts)
• Optimum smoothing thanks to more than 80,000 µF power supply capacity; Premium quality capacitors (Made in Germany)
• Very high damping factor for perfect speaker control
• Professional protective circuit against clipping, HF oscillations and too high DC offset
• Constant low operating temperature due to generously dimensioned heat sinks
• Balanced input (XLR) and unbalanced input (RCA)the inputs are switchable on the rear panel
• WBT loudspeaker terminals
• All used parts and components are selected and of highest quality Premium quality, gold-plated bi-wiring / bi-amping speaker terminals Mains power switch on the front panel
• Extremely stable and resonance optimized, massive aluminium housing; inlay made of massive, high gloss polished and chromed brass
• ACCUSTIC ARTS® MONO IV is guaranteed Handmade in Germany

MONO IV  Specifications

Voltage gain:

• 30.0 dB

Power supply capacity:

• more than 80.000 µF

Input impedance:

• balanced (XLR): 2 x 20 k
• unsym. (RCA/Cinch): 100 k

Rated power output:

• approx. 900 watts on 2
• approx. 760 watts on 4
• max. 510 watts on 8

Signal to noise ratio:

• -96 dBA (ref. 6.325 V)

Intermodulation distortion:

• 0.007 % with 10 watts on 4

Distortion (THD+N):

• 0.004 % on 4load with 1 kHz and 10 watts

Power consumption:

• approx. 120 watts (without load)

Dimensions (H x W x D)

• 340 x 470 x 440 mm / 13.4 x 18.5 x 17.3 inches

Weight:

• approx. 42 kg / 93 lbs
• + 12 kg / 27 lbs flight case
